YSW Hydraulic & Mechanical Wedges

    Yale
  • Brand: Yale
  • Availability: In Stock
  • Estimated lead time to dispatch is 2-3 Days

  • £1,719.25

Available Options


YSW Hydraulic & Mechanical Wedges

Innovative mechanical and hydraulic flange spreading wedges. Yale’s new range of hydraulic and mechanical wedges and spreaders compliment the existing range of maintenance tools.


USER FEATURES:

  • Practical, portable and lightweight
  • Moulded plastic handle for comfort
  • Revolving handle to aid horizontal or vertical spreading
  • Offset handle is directly over the centre of mass
  • Removable handle for improved access
  • Revolving lanyard connection point
  • Swivel hose coupler with elbow - improves access by allowing hose to revolve
  • Spread indicator markings for clear precise visual progress feedback

 SAFETY FEATURES

  •
  • No finger pinch-points
  • Increased step depth on upper steps
  • Safety lanyard - 1.0m length
  • Partially recessed coupler reduces coupler vulnerability
  • Forged key components for strength and reliability


MAINTENANCE FEATURES

  • Rapid disassembly and assembly
  • Quick jaw replacement - remove 1 fastener
  • Quit tip replacement - remove 2 fasteners
  • Narrow jaw teeth - improved tool wear.


Model Spreading force tonne Description Acceptance dimension mm  Spreading distance mm
YSW-14TH 14 Hydraulic lifting wedge c/w stepped blocks, safety block, and plastic storage case 6 6 - 86
YSW-14 Standard Kit 14 Comprising: 1 x YSW-14TH wedge .   1 x HPS-2/0.7A hand pump .   1 x HHC-30 hydraulic hose with couplers .  1 x HPK-10 and metal storage case 6 6 - 86
YSW-14 Maxi Kit 14 ( each) 28 (kit0 Comprising:  2 x YSW-14TH wedge .   1 x HPS-2/0.7A hand pump .  2 x HHC-30 hydraulic hose with couplers . 1 x HPK-10 metal storage case . 1 x MY-22 manifold with shut off valves .  2 x CMY-1 male quick release couplings 2 x CFY-1 female quick release couplings 2 x CDF-9 rubber dust cover for coupling 6 6 - 86
HK-16T Mini Kit 16 Comprising: Hydraulic wedge c/w stepped blocks, safety block and metal storage case 9.5 9.5 - 29.5
HK-16T Standard Kit 16 Comprising: 1 x HK-16T wedge 1 x HPS-2/0.7A hand pump 1 x HHC-30 hydraulic hose with couplers 1 x HPK-10 metal storage case 9.5 9.5 - 29.5
HK-16TM 16 Hydraulic lifting wedge with integral pump, c/w stepped blocks, safety block, and plastic storage case 9.5 9.5 - 29.5
YSW-8TM 8 Mechanical lifting wedge c/w stepped blocks, safety block, and plastic storage case 6 6 - 86

Kits are supplied as standard with the HPS2/0.7A. There is the option available to have the PYB-0.6 cordless pump instead, for an additional £1480. Call the sales team to discuss.

Technical specification Technical specification

Model Spreading force tonne Description Acceptance dimension mm  Spreading distance mm
YSW-14TH 14 Hydraulic lifting wedge c/w stepped blocks, safety block, and plastic storage case 6 6 - 86
YSW-14 Standard Kit 14 Comprising: 1 x YSW-14TH wedge .   1 x HPS-2/0.7A hand pump .   1 x HHC-30 hydraulic hose with couplers .  1 x HPK-10 and metal storage case 6 6 - 86
YSW-14 Maxi Kit 14 ( each) 28 (kit0 Comprising:  2 x YSW-14TH wedge .   1 x HPS-2/0.7A hand pump .  2 x HHC-30 hydraulic hose with couplers . 1 x HPK-10 metal storage case . 1 x MY-22 manifold with shut off valves .  2 x CMY-1 male quick release couplings 2 x CFY-1 female quick release couplings 2 x CDF-9 rubber dust cover for coupling 6 6 - 86
HK-16T Mini Kit 16 Comprising: Hydraulic wedge c/w stepped blocks, safety block and metal storage case 9.5 9.5 - 29.5
HK-16T Standard Kit 16 Comprising: 1 x HK-16T wedge 1 x HPS-2/0.7A hand pump 1 x HHC-30 hydraulic hose with couplers 1 x HPK-10 metal storage case 9.5 9.5 - 29.5
HK-16TM 16 Hydraulic lifting wedge with integral pump, c/w stepped blocks, safety block, and plastic storage case 9.5 9.5 - 29.5
YSW-8TM 8 Mechanical lifting wedge c/w stepped blocks, safety block, and plastic storage case 6 6 - 86
