MWS Spur Gear Drive Manual Wire Rope Winches

  • MWS Spur Gear Drive Manual Wire Rope Winches
    Pfaff Silberblau
  • Brand: Pfaff Silberblau
  • Availability: In Stock
  • Estimated lead time to dispatch is 1 Day

  • £281.41

Available Options


MWS, Manual winch with spur gear drive

Capacities: 150 - 1500kg

Features:

  • Enclosed gear drive for protection of internal parts, even under tough working conditions.
  • Spur gears on roller bearings, rope drum on plain bearings.
  • Compact design.
  • Easy and quick mounting onto walls, poles etc.
  • They have a self-locking, anti-kickback and adjustable crank
  • handle for fast lifting of smaller loads, resulting in lowest
  • possible handle effort and rapid winding of the rope.
  • Automatic load pressure brake for safe holding and extremely sensitive lowering of the load. Unintentional brake
  • release is prevented even with swinging loads.
  • They are suitable for operation in ambient temperatures of
  • -20°C up to +40°C.


Model Lifting capacity 1st rope layer (kg) Lifting capacity last rope layer( kg) Crank effort 1st rope layer (daN) Ratio Recommended rope diameter (mm) Minimum breaking load of wire rope (kN) Useable rope length max. (mtr) Number of rope layers max. Weight without wire rope (kg)
MWS 150 150 68 11 01:01 4 5.7 13 8 4
MWS 300 300 166 6 1:7.4 5 15.9 21 7 10
MWS 600 600 308 10 01:07.4 6 22.9 12 6 11
MWS 1000 1000 587 11 01:17 9 51 25 5 27
MWS 1500 1500 844 12 01:25.7 10 63 21 5 28

Technical specification MWS Technical specification MWS

Technical specification MWS 150 Technical specification MWS 150

Model Lifting capacity 1st rope layer (kg) Lifting capacity last rope layer( kg) Crank effort 1st rope layer (daN) Ratio Recommended rope diameter (mm) Minimum breaking load of wire rope (kN) Useable rope length max. (mtr) Number of rope layers max. Weight without wire rope (kg)
MWS 150 150 68 11 01:01 4 5.7 13 8 4
MWS 300 300 166 6 1:7.4 5 15.9 21 7 10
MWS 600 600 308 10 01:07.4 6 22.9 12 6 11
MWS 1000 1000 587 11 01:17 9 51 25 5 27
MWS 1500 1500 844 12 01:25.7 10 63 21 5 28




Model MWS 150 MWS 300 MWS 600 MWS 1000 MWS 1500
A, mm 65 200 200 230 230
B, mm 168 300 300 340 340
C, mm 128 268 268 280 280
D, mm 40 168 168 180 180
E, mm 303 318 318 485 485
G, mm 26 – – – –
H, mm 40.5 55 55 113 113
J, mm 35 70 60 102 102
K, mm 9 12 12 17 17
L, mm 102 145 145 212 212
M, mm 168 182 182 350 350
N, mm 89 199 199 266 266
O, mm 92 96 96 263 263
S, mm 128.5 128.5 128.5 128.5

128.5
